| ENGINE |
| Engine Type |
Automatic, 152FMI 1 + 1 |
| Start Type |
Electric Start |
| Transmission |
Chain Drive |
| Engine Gear |
F-N-R |
| Shift Gear |
Hand |
| Engine Capacity |
110ml |
| Max Engine Power |
4.5kw / 7500r /min |
| Max Torque |
6.9 N.m / 6000 (r /min) |
| Ignition |
CDI |
| Fuel Tank Capacity |
2.3 L |
| Maximum Speed |
31.1 MPH |
| Exhaust Pollutants (EPA) |
CO ≤ 3.8% HC ≤ 800ppm |
| Startup performance |
≤ 15s |
| Side slip |
≤ ± 5m / km |
| Braking distance |
30km /h ≤5.9m |
| Startup acceleration performance |
0-200m – 30km / h ≤18s |
| Beyond acceleration performance |
30km / h 0-200m≤16s |
| Maximum noise |
≤ 80dB |
| Climbing angle |
≥ 12 º |
| CHASSIS |
| Front Hand Brake |
Hub |
| Rear Foot Brake |
Disc Brake |
| Tire Front |
145 / 70-6 |
| Tire Rear |
145 / 70-6 |
| Front Suspension |
265mm ± 2 |
| Rear Suspension |
255mm ± 2 |
| Remote Control |
Yes |
| Speed Limiter |
Yes |
| Engine kill switch |
Yes |
| Battery |
12V/5Ah |
| Wheelbase |
863 mm |
| Turning Radius |
55.1 inches |
| Steering Angle |
30 º ± 2 º |
| Front braking force |
≥300N |
| Rear braking force |
≥350N |
| DIMENSION |
| G.W |
222.7 LBS |
| N.W |
132.3 LBS |
| Max Loading |
183 LBS |
| Seat Height |
23.23 inches |
| Ground Clearance |
2.76 inches |
| Height |
33.1 Inches |
| Width |
28.7 inches |
| Length |
52.2 inches |
| Handle tube work center width |
23 inches |
| Packaging Iron Frame |
1135 x 685 x 610 |
| Packaging Cartons |
1145 x 695 x 600 |
